What is a container?
A story about picking apart how and why containers work the way they do
A story about picking apart how and why containers work the way they do
Containers have recently become a common way of packaging, deploying and running software across a wide set of machines in all sorts of environments. With the initial release of Docker in March, 2013 containers have become ubiquitous in modern software deployment with 71% of Fortune 100 companies running it in some capacity. Containers can be used for:
Running user facing, production software
Running a software development environment
Compiling software with its dependencies in a sandbox
Analysing the behaviour of software within a sandbox
Like their namesake in the shipping industry containers are designed to easily “lift and shift” software to different environments and have that software execute in the same way across those environments.
Containers have thus earned their place in the modern software development toolkit. However to understand how container technology fits into our modern software architecture its worth understanding how we arrived at containers, as well as how they work.
In this article we’ll only be discussing Linux containers. There are container implementations on other operating systems but we do not feel qualified to discuss those just yet.
Although there are containers implemented on other operating systems Linux containers are in common use in both MacOS and Windows. In both of those operating systems these are implemented by way of virtualized hardware — a virtual machine.
According to the SCCS logs, the chroot call was added by Bill Joy on March 18, 1982 approximately 1.5 years before 4.2BSD was released. That was well before we had ftp servers of any sort (ftp did not show up in the source tree until January 1983). My best guess as to its purpose was to allow Bill to chroot into the /4.2BSD build directory and build a system using only the files, include files, etc contained in that tree. That was the only use of chroot that I remember from the early days.
— Dr. Marshall Kirk Mckusick
chroot is used to put a process into a "changed root"; a new root filesystem that has limited or no access to the parent root filesystem. An extremely minimal
chroot can be created on Linux as follows:
# Get a shell $ cd $(mktemp -d) $ mkdir bin $ $(which sh) bin/bash
# Find shared libraries required for shell $ ldd bin/sh linux-vdso.so.1 (0x00007ffe69784000) /lib/x86_64-linux-gnu/libsnoopy.so (0x00007f6cc4c33000) libc.so.6 => /lib/x86_64-linux-gnu/libc.so.6 (0x00007f6cc4a42000) libpthread.so.0 => /lib/x86_64-linux-gnu/libpthread.so.0 (0x00007f6cc4a21000) libdl.so.2 => /lib/x86_64-linux-gnu/libdl.so.2 (0x00007f6cc4a1c000) /lib64/ld-linux-x86-64.so.2 (0x00007f6cc4c66000)
# Duplicate libraries into root $ mkdir -p lib64 lib/x86_64-linux-gnu $ cp /lib/x86_64-linux-gnu/libsnoopy.so \ /lib/x86_64-linux-gnu/libc.so.6 \ /lib/x86_64-linux-gnu/libpthread.so.0 \ /lib/x86_64-linux-gnu/libdl.so.2 \ lib/x86_64-linux-gnu/
$ cp /lib64/ld-linux-x86-64.so.2 lib64/
# Change into that root $ sudo chroot .
# Test the chroot # ls /bin/bash: 1: ls: not found #
There were problems with this early implementation of
chroot, such as being able to exit that
chroot by running
cd.., but these were resolved in short order. Seeking to provide better security FreeBSD extended the
chroot into the
jail which allowed running software that desired to run as
root and running it within a confined environment that was
root within that environment but not
root elsewhere on the system.
User separation (similar to
Filesystem separation (similar to
A separate process space
Providing something similar to the modern concept of containers; processes running on the same kernel. Later, similar work took place in the Linux kernel to isolate kernel structures on a per-process basis under “namespaces”.
However, in parallel Amazon Web Services (AWS) launched their Elastic Compute Cloud (EC2) product which took a different approach to separating out workloads: virtualising the entire hardware. This has some different tradeoffs; it limits exploitation of the host kernel or isolation implementation however running the additional operating system and hypervisor meant a far less efficient use of resources.
Virtualisation continued to dominate workload isolation until the company “dotcloud” (now Docker), then operating as a “platform as a service” (PAAS) offering, open sourced the software they used to run their PAAS. With that software and a large amount of luck containers proliferated rapidly until Docker became the power house it is now.
Shortly after Docker released their container runtime they started expanding their product offerings into build, orchestration and server management tooling. Unhappy with this CoreOS created their own container runtime,
rkt, which had the stated goal of interoperating with existing services such as
systemd, following the unix philosophy of "Write programs that do one thing and do it well."
To reconcile these disaparate definitions of a container the Open Container Initiative was established, after which Docker donated its schema and its runtime as what amounted to a defacto container standard.
There are now a number of container implementations, as well as a number of standards to define their behaviour.
It might be surprising to learn that a “container” is not a real thing — rather, it is a specification. At the time of writing this specification has implementations on^:
In turn, containers are expected to be:
Consumable with a set of standard, interoperable tools
Consistent regardless of what type of software is being run
Agnostic to the underlying infrastructure the container is being run on
Designed in a way that makes automation easy
Of excellent quality
There are specifications that dictate how containers should reach these principles by defining how they should be executed (the runtime specification), what a container should contain (the image specification) and how to distribute container “images” (the distribution specification).
These specifications mean that a wide variety of tools can be used to interact with containers. The canonical tool that is in most common use is the Docker tool, which in addition to manipulating containers provides container build tooling and some limited orchestration of containers. However, there are a number of container runtimes:
As well as other tools that help with building or distributing images.
Lastly, there are extensions to the existing standards, such as the container networking interface, which define additional behaviour where the standards are not yet clear enough.
While the standards give us some idea as to what a container is and how they should work, it’s perhaps useful to understand how a container implementation works. Not all container runtimes are implemented in this way; notably, kata containers implement hardware virtualisation as alluded to earlier with EC2.
The problems being solved by containers are:
Isolation of a process(es)
Distribution of that process(es)
Connecting that process(es) to other machines
With that said let’s dive in to the Docker implementation. This uses a series of technologies exposed by the underlying kernel:
Kernel feature isolation: namespaces
man namespaces command defines namespaces as follows:
A namespace wraps a global system resource in an abstraction that makes it appear to the processes within the namespace that they have their own isolated instance of the global resource. Changes to the global resource are visible to other processes that are members of the namespace, but are invisible to other processes. One use of namespaces is to implement containers.
Paraphrased, a namespace is a slice of the system that, from within that slice, a process cannot see the rest of the system.
A process must make a system call to the Linux kernel to changes its namespace. There are several system calls:
clone: Create a new process. When used in conjunction with
CLONE_NEW*it creates a namespace of the kind specified. For example, if used with
CLONE_NEWPIDthe process will enter a new
pidnamespace and become
setns: Allows the calling process to join an existing namespace, specified under
unshare: Moves the calling process into a new namespace
There is a user command also called
unshare which allows us to experiment with namespaces. We can put ourselves into a separate process and network namespace with the following command:
# Scratch space $ cd $(mktemp -d)
# Fork is required to spawn new processes, and proc is mounted to give accurate process information $ sudo unshare \ --fork \ --pid \ --mount-proc \ --net
# Here we see that we only have access to the loopback interface root@sw-20160616-01:/tmp/tmp.XBESuNMJJS# ip addr 1: lo: <LOOPBACK> mtu 65536 qdisc noop state DOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
# Here we see that we can only see the first process (bash) and our `ps aux` invocation root@sw-20160616-01:/tmp/tmp.XBESuNMJJS# ps aux USER PID %CPU %MEM VSZ RSS TTY STAT START TIME COMMAND root 1 0.3 0.0 8304 5092 pts/7 S 05:48 0:00 -bash root 5 0.0 0.0 10888 3248 pts/7 R+ 05:49 0:00 ps aux
Docker uses the following namespaces to limit the ability for a process running in the container to see resources outside that container:
pidnamespace: Process isolation (PID: Process ID).
netnamespace: Managing network interfaces (NET: Networking).
ipcnamespace: Managing access to IPC resources (IPC: InterProcess Communication).
mntnamespace: Managing filesystem mount points (MNT: Mount).
utsnamespace: Isolating kernel and version identifiers. (UTS: Unix Timesharing System).
These provide reasonable separation between processes such that workloads should not be able to interfere with each other. However there is a notable caveat: we can disable some of this isolation.
This is an extremely useful property. One example of this would be for system daemons that need access to the host network to bind ports on the host, such as running a DNS service or service proxy in a container.
Process #1 or the
init process in Linux systems has some additional responsibilities. When processes terminate in Linux they are not automatically cleaned up, but rather simply enter a terminated state. It is the responsibility of the init process to "reap" those processes, deleting them so that their process ID can be reused. Accordingly the first process run in a Linux namespace should be an
init process, and not a user facing process like
mysql. This is known as the zombie reaping problem.
Another place namespaces are used is the Chromium browser. Chromium uses at least the
Resource isolation: control groups
The kernel documentation for
cgroups defines the cgroup as follows:
Control Groups provide a mechanism for aggregating/partitioning sets of tasks, and all their future children, into hierarchical groups with specialized behaviour.
That doesn’t really tell us much though. Luckily it expands:
On their own, the only use for cgroups is for simple job tracking. The intention is that other subsystems hook into the generic cgroup support to provide new attributes for cgroups, such as accounting/limiting the resources which processes in a cgroup can access. For example, cpusets (see Documentation/cgroup-v1/cpusets.txt) allow you to associate a set of CPUs and a set of memory nodes with the tasks in each cgroup.
cgroups are a groups of "jobs" that other systems can assign meaning to. The systems that currently use this
As well as various others.
cgroups are manipulated by reading and writing to the
/proc filesystem. For example:
# Create a cgroup called "me" $ mkdir /sys/fs/cgroup/memory/me
# Allocate the cgroup a max of 100Mb memory $ echo '100000000' | sudo tee /sys/fs/cgroup/memory/me/memory.limit_in_bytes
# Move this proess into the cgroup $ echo $$ | sudo tee /sys/fs/cgroup/memory/me/cgroup.procs 5924
That’s it! This process should now be limited to 100Mb total usage
Docker uses the same functionality in its
--cpus arguments, and it is employed by the orchestration systems Kubernetes and Apache Mesos to determine where to schedule workloads.
cgroups are most commonly associated with containers they’re already used for other workloads. The best example is perhaps
systemd, which automatically puts all services into a
cgroup if the CPU scheduler is enabled in the kernel.
systemd services are … kind of containers!
Userland isolation: seccomp
While both namespaces and
cgroups go a significant way to isolating processes into their own containers Docker goes further than that to restrict what access the process can have to the Linux kernel itself. This is enforced in supported operating systems via "SECure COMPuting with filters", also known as
seccomp-bpf or simply
The Linux kernel user space API guide defines
Seccomp filtering provides a means for a process to specify a filter for incoming system calls. The filter is expressed as a Berkeley Packet Filter (BPF) program, as with socket filters, except that the data operated on is related to the system call being made: system call number and the system call arguments.
BPF in turn is a small, in-kernel virtual machine language used in a number of kernel tracing, networking and other tasks. Whether the system supports seccomp can be determined by running the following command:
$ grep CONFIG_SECCOMP= /boot/config-$(uname -r)
# Our system supports seccomp CONFIG_SECCOMP=y
Practically this limits a processes ability to ask the kernel to do certain things. Any system call can be restricted, and docker allows the use of arbitrary seccomp “profiles” via its
docker run --rm \ -it \ --security-opt seccomp=/path/to/seccomp/profile.json \ hello-world
However, most usefully Docker provides a default security profile that limits some of the more dangerous system calls that processes run from a container should never need to make, including:
clone: The ability to clone new namespaces
bpf: The ability to load and run
add_key: The ability to access the kernel keyring
kexec_load: The ability to load a new linux kernel
As well as many others. The full list of syscalls blocked by default is available on the Docker website.
In addition to
seccomp there are other ways to ensure containers are behaving as expected, including:
Each of which take slightly different approaches of ensuring the process is only executed within expected behaviour. It’s worth spending time to investigate the tradeoffs of each of these security decisions or simply delegating the choice to a competent third party provider.
Additionally it’s worth noting that even though Docker defaults to enabling the
seccomp policy, orchestration systems such as
kubernetes may disable it.
Distribution: the union file system
To generate a container Docker requires a set of “build instructions”. A trivial image could be:
# Scratch space $ cd $(mktemp -d)
# Create a docker file $ cat <<EOF > Dockerfile FROM debian:buster
# Create a test directory RUN mkdir /test
# Create a bunch of spam files RUN echo $(date) > /test/a RUN echo $(date) > /test/b RUN echo $(date) > /test/c
# Build the image $ docker build . Sending build context to Docker daemon 4.096kB Step 1/5 : FROM debian:buster ---> ebdc13caae1e Step 2/5 : RUN mkdir /test ---> Running in a9c0fa1a56c7 Removing intermediate container a9c0fa1a56c7 ---> 6837541a46a5 Step 3/5 : RUN echo Sat 30 Mar 18:05:24 CET 2019 > /test/a ---> Running in 8b61ca022296 Removing intermediate container 8b61ca022296 ---> 3ea076dcea98 Step 4/5 : RUN echo Sat 30 Mar 18:05:24 CET 2019 > /test/b ---> Running in 940d5bcaa715 Removing intermediate container 940d5bcaa715 ---> 07b2f7a4dff8 Step 5/5 : RUN echo Sat 30 Mar 18:05:24 CET 2019 > /test/c ---> Running in 251f5d00b55f Removing intermediate container 251f5d00b55f ---> 0122a70ad0a3 Successfully built 0122a70ad0a3
This creates a docker image with the id of
0122a70ad0a3 containing the contents of
c. We can verify this by starting the container and examining its contents:
$ docker run \ --rm=true \ -it \ 0122a70ad0a3 \ /bin/bash
$ cd /test $ ls a b c $ cat *
Sat 30 Mar 18:05:24 CET 2019 Sat 30 Mar 18:05:24 CET 2019 Sat 30 Mar 18:05:24 CET 2019
However, in the
docker build command earlier Docker created several images. If we run the image after only
b have been executed we will not see
$ docker run \ --rm=true \ -it \ 07b2f7a4dff8 \ /bin/bash $ ls test a b
Docker is not creating a whole new filesystem for each of these images. Instead, each of the images are layered on top of each other. If we query Docker we can see each of the layers that go into a given image:
$ docker history 0122a70ad0a3 IMAGE CREATED CREATED BY SIZE COMMENT 0122a70ad0a3 5 minutes ago /bin/sh -c echo Sat 30 Mar 18:05:24 CET 2019… 29B 07b2f7a4dff8 5 minutes ago /bin/sh -c echo Sat 30 Mar 18:05:24 CET 2019… 29B 3ea076dcea98 5 minutes ago /bin/sh -c echo Sat 30 Mar 18:05:24 CET 2019… 29B 6837541a46a5 5 minutes ago /bin/sh -c mkdir /test 0B ebdc13caae1e 12 months ago /bin/sh -c #(nop) CMD ["bash"] 0B <missing> 12 months ago /bin/sh -c #(nop) ADD file:2219cecc89ed69975… 106MB
This allows docker to reuse vast chunks of what it downloads. For example, given the image we built earlier we can see that it uses:
A layer called
ADD file:…— this is the Debian Buster root filesystem at 106MB
A layer for
athat renders the date to disk at 29B
A layer for
bthat renders the date to disk at 29B
And so on. Docker will reuse the
Add file:… Debian Buster root for all image that start with
This allows Docker to be extremely space efficient if possible, reusing the same operating system image for multiple different executions.
Even though Docker is extremely space efficient the docker library on disk can grow extremely large and transferring large docker images over the network can become expensive. Therefore, try to reuse image layers where possible and prefer smaller operating systems or the
scratch (nothing) image where possible.
These layers are implemented via a Union Filesystem, or UnionFS. There are various “backends” or filesystems that can implement this approach:
Generally speaking the package manager on our machine will include the appropriate underlying filesystem driver; docker supports many:
$ docker info | grep Storage Storage Driver: overlay2
We can replicate this implementation with our overlay mount fairly easily:
# scratch cd $(mktemp -d)
# Create some layers $ mkdir \ lower \ upper \ workdir \ overlay
# Create some files that represent the layers $ touch lower/i-am-the-lower $ touch higher/i-am-the-higher
# Create the layered filesystem at overlay with lower, upper and workdir $ mount -t overlay \ -o lowerdir=lower,upperdir=upper,workdir=workdir \ ./overlay \ overlay
# List the directory $ ls overlay/ i-am-the-lower i-am-the-upper
Docker goes so far as to nest those layers until the multi-layered filesystem has been successfully implemented.
Files that are written are written back to the
upper directory, in the case of
overlay2. However Docker will generally dispose of these temporary files when the container is removed.
Generally speaking all software needs access to shared libraries found in static paths in Linux operating systems. Accordingly it is the convention to simply ship a stripped down version of an operating systems root file system such that users can install and applications can find the libraries they expect. However, it is possible to use an empty filesystem and a statically compiled binary with the
scratch image type.
As mentioned earlier, containers make use of Linux namespaces. Of particular interest when understanding container networking is the network namespace. This namespace gives the process separate:
(virtual) ethernet devices
# Create a new network namespace $ sudo unshare --fork --net
# List the ethernet devices with associated ip addresses $ ip addr 1: lo: <LOOPBACK> mtu 65536 qdisc noop state DOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
# List all iptables rules root@sw-20160616-01:/home/andrewhowden# iptables -L Chain INPUT (policy ACCEPT) target prot opt source destination
Chain FORWARD (policy ACCEPT) target prot opt source destination
Chain OUTPUT (policy ACCEPT) target prot opt source destination
# List all network routes $ ip route show
By default, the container has no network connectivity — not even the
loopback adapter is up. We cannot even ping ourselves!
$ ping 127.0.0.1 PING 127.0.0.1 (127.0.0.1): 56 data bytes ping: sending packet: Network is unreachable
We can start setting up the expected network environment by bringing up the
$ ip link set lo up root@sw-20160616-01:/home/andrewhowden# ip addr 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 inet 127.0.0.1/8 scope host lo valid_lft forever preferred_lft forever inet6 ::1/128 scope host valid_lft forever preferred_lft forever
# Test the loopback adapter $ ping 127.0.0.1 PING 127.0.0.1 (127.0.0.1): 56 data bytes 64 bytes from 127.0.0.1: icmp_seq=0 ttl=64 time=0.092 ms 64 bytes from 127.0.0.1: icmp_seq=1 ttl=64 time=0.068 ms
However, we cannot access the outside world. In most environments our host machine will be connected via ethernet to a given network and either have an IP assigned to it via the cloud provider or, in the case of a development or office machine, request an IP via DHCP. However our container is in a network namespace of its own and has no knowledge of the ethernet connected to the host. To connect the container to the host we need to employ a
veth, or "Virtual Ethernet Device" is defined by
man vetTo create a `veth device we can run as:
The veth devices are virtual Ethernet devices. They can act as tunnels between network namespaces to create a bridge to a physical network device in another namespace, but can also be used as standalone network devices.
$ echo $$ 18171
We can then create the
$ sudo ip link add veth0 type veth peer name veth0 netns 18171
We can see both on the host and the guest these virtual ethernet devices appear. However, neither has an IP attached nor any routes defined:
$ ip addr 1: lo: <LOOPBACK> mtu 65536 qdisc noop state DOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 2: veth0@if7: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN group default qlen 1000 link/ether 16:34:52:54:a2:a1 brd ff:ff:ff:ff:ff:ff link-netnsid 0 $ ip route show
# No output
To address that we simply add an IP and define the default route:
# On the host $ ip addr add 192.168.24.1 dev veth0
# Within the container $ ip address add 192.168.24.10 dev veth0
From there, bring the devices up:
# Both host and container $ ip link set veth0 up
Add a route such that
192.168.24.0/24 goes out via
# Both host and guest ip route add 192.168.24.0/24 dev veth0
And voilà! We have connectivity to the host namespace and back:
# Within container $ ping 192.168.24.1 PING 192.168.24.1 (192.168.24.1): 56 data bytes 64 bytes from 192.168.24.1: icmp_seq=0 ttl=64 time=0.149 ms 64 bytes from 192.168.24.1: icmp_seq=1 ttl=64 time=0.096 ms 64 bytes from 192.168.24.1: icmp_seq=2 ttl=64 time=0.104 ms 64 bytes from 192.168.24.1: icmp_seq=3 ttl=64 time=0.100 ms
However, that does not give us access to the wider internet. While the
veth adapter functions as a virtual cable between our container and our host, there is currently no path from our container to the internet:
# Within container $ ping google.com ping: unknown host
To create such a path we need to modify our host such that it functions as a “router” between its own, separated network namespaces and its internet facing adapter.
Luckily, Linux is set up well for this purpose. First, we need to modify the normal behaviour of Linux from dropping packets not destined for IP addresses with which their associated but rather allow forwarding a packet from one adapter to the other:
# Within container $ echo 1 > /proc/sys/net/ipv4/ip_forward
That means when we request public facing IPs from within our container via our
veth adapter to our host
veth adapter the host adapter won’t simply drop those packets.
From there we employ
iptables rules on the host to forward traffic from the host
veth adapter to the internet facing adapter — in this case
# On the host # Forward packets from the container to the host adapter iptables -A FORWARD -i veth0 -o wlp2s0 -j ACCEPT
# Forward packets that have been established via egress from the host adapater back to the contianer iptables -A FORWARD -i wlp2s0 -o veth0 -m state --state ESTABLISHED,RELATED -j ACCEPT
# Relabel the IPs for the container so return traffic will be routed correctly iptables -t nat -A POSTROUTING -o wlp2s0 -j MASQUERADE
We then tell our container to send traffic it doesn’t know anything else about down the
# Within the container $ ip route add default via 192.168.24.1 dev veth0
And the internet works!
$ # ping google.com PING google.com (126.96.36.199): 56 data bytes 64 bytes from 188.8.131.52: icmp_seq=0 ttl=55 time=16.456 ms 64 bytes from 184.108.40.206: icmp_seq=1 ttl=55 time=15.102 ms 64 bytes from 220.127.116.11: icmp_seq=2 ttl=55 time=34.369 ms 64 bytes from 18.104.22.168: icmp_seq=3 ttl=55 time=15.319 ms
As mentioned, each container implementation can implement networking differently. There are implementations that use the aforementioned
BPF or other cloud specific implementations. However, when designing containers we need some way to reason about what behaviour we should expect.
To help address this the “Container Network Interface” tooling has been designed. This allows defining consistent network behaviour across network implementations, as well as models such as Kubernetes shared
lo adapter between several containers.
The networking side of containers is an area undergoing rapid innovation but relying on:
A public facing
eth0(or similar) interface
being present seems a fairly stable guarantee.
Given our understanding of the implementation of containers we can now take a look at some of the classic docker discussions.
One of the oft overlooked parts of containers is the necessity to keep both them, and the host system up to date.
In modern systems it is quite common to simply enable automatic updates on host systems and, so long as we stick to the system package manager and ensure updates stay successful, the system will keep itself both up to date and stable.
However, containers take a very different approach. They’re effectively giant static binaries deployed into a production system. In this capacity they can do no self maintenance.
Accordingly even if there are no updates to the software the container runs, containers should be periodically rebuilt and redeployed to the production system — less they accumulate vulnerabilities over time.
Init within container
Given our understanding of containers its reasonable to consider the “1 process per container” advice and determine that it is an oversimplification of how containers work, and it makes sense in some cases to do service management within a container with a system like
This allows multiple processes to be executed within a single container including things like:
And so forth
In the case where Docker is the only system that is being used it is indeed reasonable to think about doing service management within docker — particularly when hitting the constraints of shared filesystem or network state. However systems such as Kubernetes, Swarm or Mesos have replaced much of the necessity of these init systems; tasks such as log aggregation, restarting services or colocating services are taken care of by these tools.
Accordingly its best to keep containers simple such that they are maximally composable and easy to debug, delegating the more complex behaviour out.
Containers are an excellent way to ship software to production systems. They solve a swathe of interesting problems and cost very little as a result. However, their rapid growth has meant some confusion in industry as to exactly how they work, whether they’re stable and so fourth. Containers are a combination of both old and new Linux kernel technology such as namespaces, cgroups, seccomp and other Linux networking tooling but are as stable as any other kernel technology (so, very) and well suited for production systems.
❤ for making it this far.
“Docker.” https://en.wikipedia.org/wiki/Docker_(software) .
“Cloud Native Technologies in the Fortune 100.” https://redmonk.com/fryan/2017/09/10/cloud-native-technologies-in-the-fortune-100/ , Sep-2017.
B. Cantrill, “The Container Revolution: Reflections After the First Decade.” https://www.youtube.com/watch?v=xXWaECk9XqM , Sep-2018.
“Papers (Jail).” https://docs.freebsd.org/44doc/papers/jail/jail.html .
“An absolutely minimal chroot.” https://sagar.se/an-absolutely-minimal-chroot.html , Jan-2011.
J. Beck et al., “Virtualization and Namespace Isolation in the Solaris Operating System (PSARC/2002/174).” https://us-east.manta.joyent.com/jmc/public/opensolaris/ARChive/PSARC/2002/174/zones-design.spec.opensolaris.pdf , Sep-2006.
M. Kerrisk, “Namespaces in operation, part 1: namespaces overview.” https://lwn.net/Articles/531114/ , Jan-2013.
A. Polvi, “CoreOS is building a container runtime, rkt.” https://coreos.com/blog/rocket.html , Jan-2014.
“Basics of the Unix Philosophy.” http://www.catb.org/ esr/writings/taoup/html/ch01s06.html .
P. Estes and M. Brown, “OCI Image Support Comes to Open Source Docker Registry.” https://www.opencontainers.org/blog/2018/10/11/oci-image-support-comes-to-open-source-docker-registry , Oct-2018.
“Open Container Initiative Runtime Specification.” https://github.com/opencontainers/runtime-spec/blob/74b670efb921f9008dcdfc96145133e5b66cca5c/spec.md , Mar-2018.
“The 5 principles of Standard Containers.” https://github.com/opencontainers/runtime-spec/blob/74b670efb921f9008dcdfc96145133e5b66cca5c/principles.md , Dec-2016.
“Open Container Initiative Image Specification.” https://github.com/opencontainers/image-spec/blob/db4d6de99a2adf83a672147d5f05a2e039e68ab6/spec.md , Jun-2017.
“Open Container Initiative Distribution Specification.” https://github.com/opencontainers/distribution-spec/blob/d93cfa52800990932d24f86fd233070ad9adc5e0/spec.md , Mar-2019.
“Docker Overview.” https://docs.docker.com/engine/docker-overview/ .
J. Frazelle, “Containers aka crazy user space fun.” https://www.youtube.com/watch?v=7mzbIOtcIaQ , Jan-2018.
“Use Host Networking.” https://docs.docker.com/network/host/ .
Krallin, “Tini: A tini but valid init for containers.” https://github.com/krallin/tini , Nov-2018.
[[0pointer.resources]]L. Poettering, “systemd for Administrators, Part XVIII.” http://0pointer.de/blog/projects/resources.html , Oct-2012.
A. Howden, “Coming to grips with eBPF.” https://www.littleman.co/articles/coming-to-grips-with-ebpf/ , Mar-2019.
“Seccomp security profiles for docker.” https://docs.docker.com/engine/security/seccomp/ .
“Linux kernel capabilities.” https://docs.docker.com/engine/security/security/#linux-kernel-capabilities .
M. Stemm, “SELinux, Seccomp, Sysdig Falco, and you: A technical discussion.” https://sysdig.com/blog/selinux-seccomp-falco-technical-discussion/ , Dec-2016.
“Pod Security Policies.” https://kubernetes.io/docs/concepts/policy/pod-security-policy/#seccomp .
Programster, “Example OverlayFS Usage.” https://askubuntu.com/a/704358 , Nov-2015.
“How do I connect a veth device inside an ’anonymous’ network namespace to one outside?” https://unix.stackexchange.com/a/396210 , Oct-2017.
D. P. García, “Network namespaces.” https://blogs.igalia.com/dpino/2016/04/10/network-namespaces/ , Apr-2016.
Originally published at www.littleman.co on March 27, 2018.
